Synology DS1621XS+



Who Offers the Best Price and Service for the Synology DS1621XS+ NAS?



WRONG COUNTRY? CLICK ON THE FLAG TO CHANGE IT
To be kept upto date on the latest price changes on the DS1621XS+, use our Amazon price watch tool to get regular, tailored updates on when it is at the best price for your budget.
Your email will ONLY be used to update you. It will never be given to a third party without your consent!
Create Amazon Price Watch
Price Watch
We'll send an email to When the Amazon Price Drops to
Last updated: 2024-11-05 20:55 [Links below are Amazon affiliate links]
Synology DiskStation DS1621xs+ NAS Server with Xeon 2.2GHz CPU, 32GB Memory, 12TB HDD Storage, 🛈3099.000 USD
Synology DiskStation DS1621xs+ NAS Server with Xeon 2.2GHz CPU, 32GB Memory, 6TB SSD Storage, 1 🛈3499.000 USD


FRESH DEALS
OPEN FULL LIST


ON YOUTUBE
Getting latest videos with a keyword: DS1621XS+

RELATED POSTS

32GB & 64GB Unofficial Memory Guide for the Synology DS1621xs+ NAS
32GB & 64GB Unofficial Memory Guide for the Synology DS1621xs+ NAS
QNAP TVS-672X vs Synology DS1621xs+ NAS Drive Comparison
Synology DS1621xs+ vs QNAP TVS-672X NAS Drive Comparison
DS1621+ vs DS1621XS+
DS1621xs+ RAM upgrade
DS1621xs+ vs DS1520+
Synology DS1621+ vs DS1621xs+ NAS Comparison
Synology DS1621xs+ NAS Plex 4K, 1080p and 720p Tests (H.264 & HEVC)
Synology DS1621xs+ NAS Review


PERFORMANCE:
SpecsMeasureDS1621xs+
10GbE iSCSI Random IOPS 4KBRead IOPS/Write IOPS169967 / 74646
1GbE Web Server PHP Response EfficiencyResponses per second 64731
Aggregated 10GbE SMB Random IOPS 4KBRead IOPS/Write IOPS132622 / 75114
Aggregated 10GbE SMB Sequential Throughput 64KBRead MBs/Write MBs3128 / 1890
Aggregated 10GbE SMB Sequential Throughput via Encrypted Shared Folder 64KBRead MBs/Write MBs2685 / 994
SSD Cache 10GbE iSCSI random access 4KBRead IOPS/Write IOPS113957 / 84015
SSD Cache 10GbE SMB random access 4KBRead IOPS/Write IOPS117203 / 84454
SpecsDS1621xs+

Specification:
SpecsValue
CPU-Model Intel Xeon D-1527
CPU Architecture 64-bit
CPU Frequency 4-core 2.2 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI)
System-memory 8 GB DDR4 ECC SODIMM
Memory Module Pre-installed 8 GB (8 GB x 1)
Total Memory Slots 2
Maximum Memory Capacity 32 GB (16 GB x 2)
Notes The specifications vary depending on system configuration and memory size.
Drive Bays 6
Maximum Drive Bays with Expansion Unit 16 (DX517 x 2)
M2-slots 2 (NVMe)
Maximum Single Volume Size*
  • 200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
  • 108 TB
Hot Swappable Drive
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port 1
USB 3.0 Port 3
eSATA Port 2
PCIe Expansion 1 x Gen3 x8 slot (x8 link)
Internal Drives
  • Btrfs
  • EXT4
External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
Size (Height x Width x Depth) 166 mm x 282 mm x 243 mm
Weight 5.3 kg
System Fan 92 mm x 92 mm x 2 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Easy Replacement System Fan
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 25.2 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 250 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power-Consumption 62.85 W (Access)
34.26 W (HDD Hibernation)
British Thermal Unit 214.45 BTU/hr (Access)
116.89 BTU/hr (HDD Hibernation)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
  • EAC
  • VCCI
  • CCC
  • RCM
  • KC
  • FCC
  • CE
  • BSMI
Warranty 5 Years
Environment RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
  • DDR4 ECC SODIMM: D4ES01-8G
  • DDR4 ECC SODIMM: D4ECSO-2666-16G
  • Expansion Units: DX517
  • 2.5" SATA SSD: SAT5200
  • M.2 2280 NVMe SSD: SNV3400
  • 10GbE Network Interface Card: E10G18-T2/E10G18-T1/E10G17-F2
  • VisualStation: VS960HD/VS360HD
  • Surveillance Device License Pack
Maximum Internal Volume Number 256
Maximum iSCSI Target Number 256
Maximum iSCSI LUN 512
iSCSI LUN Clone/Snapshot, Windows ODX
SSD Read / Write Cache (White Paper)
SSD TRIM
RAID Group
Supported RAID Type
  • RAID F1
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5
  • RAID 1 to RAID 5
  • RAID 5 to RAID 6
Volume Expansion with Larger HDDs
  • RAID F1
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
Volume Expansion by Adding a HDD
  • RAID F1
  • JBOD
  • RAID 5
  • RAID 6
Global Hot Spare Supported RAID Type
  • RAID F1
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
File Protocol CIFS/AFP/NFS/FTP/WebDAV
Maximum Concurrent CIFS/AFP/FTP Connections 2,000
Windows Access Control List (ACL) Integration
NFS Kerberos Authentication
Maximum Local User Accounts 16,000
Maximum Local Groups 512
Maximum Shared Folder 512
Maximum Shared Folder Sync Tasks 32
Synology High Availability
Log Center
Syslog Events per Second 1,500
VMware vSphere 6 with VAAI
Windows Server 2016
Windows Server 2019
Citrix Ready
OpenStack
Networking Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Supported Browsers
  • Chrome
  • Firefox
  • Edge
  • Internet Explorer 10 onwards
  • Safari 10 onwards
  • Safari (iOS 10 onwards)
  • Chrome (Android 6.0 onwards)
Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文
Antivirus by McAfee (Trial)
Central Management System
Synology Chat
Maximum Users 2,900
Document Viewer
Download Station
Maximum Concurrent Download Tasks 80
exFAT Access (Optional)
Synology MailPlus / MailPlus Server
Free Email Accounts 5 (Licenses required for additional accounts)
Maximum Number of Concurrent Users 450
Maximum Server Performance 3,363,000 emails per day, approx. 102GB
Media Server
DLNA Compliance
Moments
Facial Recognition
Subject Recognition
Auto Color & Rotate
Moments Select
Snapshot Replication
Maximum Snapshots per Shared Folder 1,024
Maximum of System Snapshots 65,536
Surveillance Station
Maximum IP cam (Licenses required) 75 (including 2 Free License) (See All Supported IP Cameras)
Total FPS (H.264) 2250 FPS @ 720p (1280x720)
1050 FPS @ 1080p (1920x1080)
600 FPS @ 3M (2048x1536)
400 FPS @ 5M (2591x1944)
280 FPS @ 4K (3840x2160)
Total FPS (H.265) 2250 FPS @ 720p (1280x720)
2250 FPS @ 1080p (1920x1080)
1125 FPS @ 3M (2048x1536)
700 FPS @ 5M (2591x1944)
490 FPS @ 4K (3840x2160)
Synology Drive
Recommended Number of Hosted Files 3,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
Recommended Number of Concurrent Sync Clients 900 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Synology Office
Video Station
Virtual Machine Manager
Recommended Virtual Machine Instances 8 (Learn more)
VPN Server
Maximum Connections 40
SpecsValue
