Synology DS920+ |
Who Offers the Best Price and Service for the Synology DS920+ NAS?
| Where to Buy a Product | |||
 |

|

|
VISIT RETAILER ➤ |
 |
|
|
VISIT RETAILER ➤ |
 |
|
|
VISIT RETAILER ➤ |
 |
|
|
VISIT RETAILER ➤ |
 |
|
|
VISIT RETAILER ➤ |
To be kept upto date on the latest price changes on the DS920+, use our Amazon price watch tool to get regular, tailored updates on when it is at the best price for your budget.
Your email will ONLY be used to update you. It will never be given to a third party without your consent!
FRESH DEALS
OPEN FULL LIST
ON YOUTUBE
Getting latest videos with a keyword: DS920+
RELATED POSTS
Synology DS920+ NAS Noctua Fans and Velcro Guide
Synology NAS Noctua Fans and Velcro Tutorial - DS923+ / DS423+ / DS920+ / DS420+ / DS918+
Synology NAS Noctua Fans and Velcro Mod - DS923+ / DS423+ / DS920+ / DS420+ / DS918+
The Synology DS920+ NAS is BACK! Sort Of...Synology Certified Refurbished NAS!
Synology DS423+ vs DS920+
Synology DS920+ 4K PLEX NAS TESTS!
Terramaster F4-423 vs Synology DS920+ NAS - Which Should You Buy?
Synology DS920+ vs Terramaster F4-423 NAS Comparison
Synology DS920+ vs DS923+ NAS - Which Should You Choose?
Synology DS923+ AMD R1600 vs Synology DS920+ Intel J4125 Celeon - Which Is Better?
PERFORMANCE:
| Specs | Measure | DS920+ |
|---|---|---|
| 1GbE AFP Mac File Transfer 1MB file x 3000 | AFP Download MBs/AFP Upload MBs | 71 / 60 |
| 1GbE AFP Mac File Transfer 3GB file x 1 | AFP Download MBs/AFP Upload MBs | 95 / 94 |
| 1GbE SMB Sequential Throughput 64KB | Read MBs/Write MBs | 226 / 226 |
| 1GbE SMB Sequential Throughput via Encrypted Shared Folder 64KB | Read MBs/Write MBs | 226 / 226 |
| 1GbE SMB Windows File Transfer 1MB file x 3000 | Windows Download MBs/Windows Upload MBs | 94 / 70 |
| 1GbE SMB Windows File Transfer via Encrypted Shared Folder 1MB file x 3000 | Windows Download MBs/Windows Upload MBs | 87 / 48 |
| 1GbE Web Server PHP Response Efficiency | Responses per second | 32720 |
| SSD Cache 1GbE iSCSI random access 4KB | Read IOPS/Write IOPS | 51273 / 35206 |
| SSD Cache 1GbE SMB random access 4KB | Read IOPS/Write IOPS | 42872 / 40880 |
| Specs | DS920+ |
Specification:
| Specs | Value |
|---|---|
| USB 3.0 Port | 2 |
| eSATA Port | 1 |
| Internal Drives |
|
| External Drives |
|
| Size (Height x Width x Depth) | 166 mm x 199 mm x 223 mm |
| Weight | 2.24 kg |
| System Fan | 92 mm x 92 mm x 2 pcs |
| Fan Speed Mode |
|
| Brightness Adjustable Front LED Indicators | |
| Power Recovery | |
| Noise Level* | 19.8 dB(A) |
| Scheduled Power On / Off | |
| Wake on LAN / WAN | |
| Power Supply Unit / Adapter | 100 W |
| AC Input Power Voltage | 100 V to 240 V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power-Consumption |
32.17 W (Access) 9.69 W (HDD Hibernation) |
| British Thermal Unit |
109.84 BTU/hr (Access) 33.09 BTU/hr (HDD Hibernation) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification |
|
| Warranty | 3 Years |
| Environment | RoHS Compliant |
| Packaging Content |
|
| Optional Accessories |
|
| Maximum Internal Volume Number | 64 |
| Maximum iSCSI Target Number | 128 |
| Maximum iSCSI LUN | 256 |
| iSCSI LUN Clone/Snapshot, Windows ODX | |
| SSD Read / Write Cache (White Paper) | |
| SSD TRIM | |
| Supported RAID Type |
|
| RAID Migration |
|
| Volume Expansion with Larger HDDs |
|
| Volume Expansion by Adding a HDD |
|
| Global Hot Spare Supported RAID Type |
|
| File Protocol | CIFS/AFP/NFS/FTP/WebDAV |
| Maximum Concurrent CIFS/AFP/FTP Connections | 1,000 |
| Windows Access Control List (ACL) Integration | |
| NFS Kerberos Authentication | |
| Maximum Local User Accounts | 2,048 |
| Maximum Local Groups | 256 |
| Maximum Shared Folder | 512 |
| Maximum Shared Folder Sync Tasks | 16 |
| Synology High Availability | |
| Log Center | |
| Syslog Events per Second | 800 |
| VMware vSphere 6 with VAAI | |
| Windows Server 2016 | |
| Windows Server 2019 | |
| Citrix Ready | |
| OpenStack | |
| Networking Protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| Supported Browsers |
|
| Supported Language | English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文 |
| CPU-Model | Intel Celeron J4125 |
| Antivirus by McAfee (Trial) | |
| Central Management System | |
| CPU Architecture | 64-bit |
| Synology Chat | |
| Maximum Users | 3,400 |
| CPU Frequency | 4-core 2.0 (base) / 2.7 (burst) GHz |
| Document Viewer | |
| Download Station | |
| Hardware Encryption Engine (AES-NI) | |
| Maximum Concurrent Download Tasks | 80 |
| exFAT Access (Optional) | |
| System-memory | 4 GB DDR4 non-ECC |
| Synology MailPlus / MailPlus Server | |
| Free Email Accounts | 5 (Licenses required for additional accounts) |
| Total Memory Slots | 1 |
| Maximum Number of Concurrent Users | 100 |
| Maximum Memory Capacity | 8 GB (4 GB + 4 GB) |
| Maximum Server Performance | 1,224,000 emails per day, approx. 37GB |
| Notes | The specifications vary depending on system configuration and memory size. |
| Drive Bays | 4 |
| Maximum Drive Bays with Expansion Unit | 9 (DX517 x 1) |
| M2-slots | 2 (NVMe) |
| Maximum Single Volume Size* | 108 TB |
| Hot Swappable Drive | |
| RJ-45 1GbE LAN Port | 2 (with Link Aggregation / Failover support) |
| Media Server | |
| DLNA Compliance | |
| Moments | |
| Facial Recognition | |
| Subject Recognition | |
| Auto Color & Rotate | |
| Moments Select | |
| Snapshot Replication | |
| Maximum Snapshots per Shared Folder | 1,024 |
| Maximum of System Snapshots | 65,536 |
| Surveillance Station | |
| Maximum IP cam (Licenses required) | 40 (including 2 Free License) (See All Supported IP Cameras) |
| Total FPS (H.264) |
1200 FPS @ 720p (1280x720) 1050 FPS @ 1080p (1920x1080) 600 FPS @ 3M (2048x1536) 360 FPS @ 5M (2591x1944) 200 FPS @ 4K (3840x2160) |
| Total FPS (H.265) |
1200 FPS @ 720p (1280x720) 1200 FPS @ 1080p (1920x1080) 1000 FPS @ 3M (2048x1536) 600 FPS @ 5M (2591x1944) 300 FPS @ 4K (3840x2160) |
| Total FPS (MJPEG) |
680 FPS @ 720p (1280x720) 400 FPS @ 1080p (1920x1080) 300 FPS @ 3M (2048x1536) 200 FPS @ 5M (2591x1944) |
| Synology Drive | |
| Recommended Number of Hosted Files | 500,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above) |
| Recommended Number of Concurrent Sync Clients | 600 (the number of connections that can be maintained when the recommended number of hosted files was reached) |
| Synology Office | |
| Video Station | |
| Virtual Machine Manager | |
| Recommended Virtual Machine Instances | 4 (Learn more) |
| VPN Server | |
| Maximum Connections | 30 |
| Specs | Value |
